Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: Tongli Machinery
  • Model Number: HR 50A
  • Voltage: 380v
  • Power(W): 15kw
  • Weight: 0.8t
  • Dimension(L*W*H): 1.6*0.65*1.4
  • Certification: CE
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Capacity: 100kg/hour
  • Color: red green blue grey
  • Product name: charcoal making machine
  • Briquette Shape: Square Customized

Packaging & Delivery

Packaging Details wooden case or as per your request
Delivery Time Shipped in 30 days after payment

  Sawdust Extruder Machine/Shisha Charcoal Press Machine/BBQ Charcoal Making Machine/Hookah Charocal Machine



1.Equipment features:

Making briquette is fast(the briquette is 60cm/20s), Large extrusion density, propeller with special wear-resistant materials, precision casting, life was over ten times more rapid than conventional.

Forming the sleeve with a specially formulated alloy casting, life span of a year. This sophisticated technique not only made the costs come down greatly but also saves manpower.



2. Raw material of charcoal briquette machine

 Sawdust, wood chips, branches, crop stalks, sugarcane residue, coffee husk, paddy straw, sunflower stalk, cotton stalks, bamboo dust, palm husk, soybeans husk, tea waste, etc.





3. Features of charcoal briquette machine

Making briquette is fast(the briquette is 60cm/20s), Large extrusion density, propeller with special wear-resistant materials, precision casting, life was over ten times more rapid than conventional.
Forming the sleeve with a specially formulated alloy casting, life span of a year. This sophisticated technique not only lowers the cost greatly but also saves manpower.





4.Working principle of  charcoal briquette machine

Briquetting is a process that biomass is compressed under high pressure and high temperature.

The self bonding of biomass to form a briquette involves the thermo plastic flow of the biomass. The lignin content that occurs naturally in biomass is liberated under high pressure and temperature. Lignin serves as the glue in the briquetting process, thus binding, compressing the biomass to form into high density briquettes.







 5. Technical parameters of  charcoal briquette machine



Model

HR 50A

HR 50B

HR 50C

Capacity

260-280kg/h

300-320kg/h

320-340kg/h

Power

15kw

18.5kw

22kw

Weight

0.8t

0.9t

0.95t

Diameter of briquette

60mm

70mm

80mm

Spare parts

PropellerForming tubeHeating ring

Shapes of finished product

Hexagonal and Square

Raw materials

Moisture (8-12%), Diameter(3-5mm)



6. Product Flow of  charcoal briquette machine

1. Crushing the raw materials into size no bigger than 5mm.

2. Dry the crushed materials to 8-12%.

3. Pressing to raw material into briquette.







7. Finished products





8. Guarantee and payment

1. Guarantee Time: All the equipments are one year, for the motors are 3months
2. Delivery Time: Within 30days after the advanced payment.
3. Payment Term: 30% T/T in advance,70% T/T before delivery.
